12 Amp Corded Electronic 2.25 Horse Power Variable Speed Fixed-Base

12 Amp Corded Electronic 2.25 Horse Power Variable Speed Fixed-Base Router

Use for precise bit plunging, edge forming, slot cutting and more

Rounded hardwood handles maximize user control

Includes: RA1161 fixed-base with system for adjusting bit height

The Bosch 1617EVS 2.25 HP Electronic Fixed-Base Router has the power to get results, with a 12 Amp motor and adjustable speed settings. The variable-speed dial allows the operator to set the optimal speed. Constant Response Circuitry, the router will maintain a constant speed throughout the cut, resulting in clean, accurate product. Users can glide along the intended cutline using dovetail fixtures, templates, jigs and other guidance devices. The Bosch Precision Centering Design allows the bit to be centered with the sub-base or optional template guides.

12 Amp router motor - combines ample power with adjustable speed settings, allowing users to glide along cutlines

Constant Response circuitry stabilizes start-up torque

Adjustable speed dial (8000-25,000 RPM)

Microfine bit-depth adjustment

Rounded hardwood handles maximize user control

Right or left switch location - for user preference and consistency (motor does not rotate during depth adjustment)

Threaded three-hole base pattern

Dust-sealed power switch

One-piece armature shaft

2 In. sub-base opening

Fixed base has threaded holes for mounting to router table positioned in common 3-hole pattern

Double insulated

Power switch - now includes dust-sealed power switch

Now includes RA1161 fixed-base with system for adjusting bit height from above a router table

Compatible with optional RA1129 Template Guide Adapter Set - for easy change of Bosch quick-release template guides and common threaded template guides; includes RA1126 Template Guide Adapter and RA1100 Interface for Threaded Template Guides

Includes : 1/4" S. R. Collet Chuck, 1/2" S. R. Collet Chuck, 16mm Shaft Wrench, Collet Nut Wrench, Chip Shield, Fixed Base (RA1161), T-Handle Hex Height Adjustment Wrench, Pack of 3 10-24 Screws for Table Mounting

Warranty - Limited 1 year

Amperage (A) 12 Collet Size (in) 1/2 in. Color Family Blue Condition New Cord Length (ft) 10 Corded Tool Type Router Cordless/Corded Corded Horsepower (HP) 2.25 hp Included Dust Collection Maximum Speed (RPM) 25000 RPM Portability Handheld Power Tool Features Depth Adjustment,Variable Speed Product Weight (lb) 10.23 Returnable 90-Day Router Base Type Fixed Base Tools Product Type Power Tool Certifications and Listings CSA Listed,UL Listed Manufacturer Warranty 1 Year Product Depth (in) 12.26 Product Height (in) 7.75 in Product Width (in) 10.1 in
10.1 inches x 12.26 inches x 7.75 inches. Weight: 10.23 lb

Returns Accepted for this item if it's within 30 Days
